The smallest automated packaging solution available
The X4® is the first Right-sized Packaging on Demand® machine system to combine four packaging functions into one.
300 boxes per hour
Produce a box every 12 seconds
29’ x 9’ 11”
Fully-loaded footprint
4 functions
fully-automated
Free up warehouse space
The X4’s small footprint and functionality allows for a box to be erected and inducted onto a conveyor line, placed on a cart, or packaged right next to the machine. Packsize Care offers support to design the most efficient workflow to ensure that the X4 works for you.
Small Footprint
The X4 takes up just 134.5 square feet, which frees up warehouse space and allows the machine to be placed however it’s needed for each individual workflow.
Reduce DIM Charges
The X4’s On Demand Packaging solution lowers your material shipping costs and your Dimensional Weight (DIM) charges. By creating right-sized boxes on demand, you’ll be able to reduce the average size of your boxes by up to 40%.
Automated Packaging
A key to automation is reducing time, touch, and travel. The X4 creates ready-to-ship boxes every 12 seconds without any labor required.
Reduce Labor
The X4 reduces labor through a 4-in-1 function, which produces the right-sized box without the need for a constant operator. This will allow you to move employees to where they are most needed without requiring your business to hire additional warehouse workers.
4-machines-in-1
The X4 is able to cut, crease, glue, and label custom shipping boxes that have been right-sized to your products.

z-Fold infeed
Label Print and Apply
Box output
Glue System

X4 Specs
Length
11″
Height
9’6″
Width
11′
Weight
4,200 lbs (1905 kg)
Footprint with Bales:
22′ 9″ x 11′
Shipping Dimensions
9’ 7/8” x 7’ 1/2” x 7’
Electrical
Single Phase 230/240 VAC, PE, 50/60 Hz, 30A
Air
Dry air pressure @ 87-145 psi (6-10 bar) and 1/2” inner
See the X4 in action in your packaging environment.
Let us customize a packaging solution that’s right for you.
